PCBの分離器機械
>
Multi Blade PCB Separator Machine Unlimited Cutting Length 220VAC

Multi Blade PCB Separator Machine Unlimited Cutting Length 220VAC

Brand Name: Winsmart
Model Number: SMTAD10
MOQ: 1セット
価格: USD1-10000/set
Packaging Details: 合板の箱
Payment Terms: L/C、T/T、ウェスタン・ユニオン
Detail Information
起源の場所:
中国
証明:
CE
電圧:
220Vac
条件:
新しい
PCBの厚さ:
1.0から3.5mm
保証:
1年
最高の切断長さ:
無制限
製品名:
マルチ ブレードPCB Depaneling機械
供給の能力:
1ヶ月あたりの200セット
ハイライト:

220VAC PCBの分離器機械、無制限の切断長さPCBの分離器機械、多刃PCBの分離器機械

,

Unlimited Cutting Length PCB Separator Machine

,

Multi Blades PCB Separator Machine

Product Description

Automatic LED Strip Cutting Machine Multi-Blade PCB Cutter Machine



Features:

1. It can cut many boards with multiple sets of knives work at the same time..

2. The knife distance can be adjustable by spacer.

3. The distance between knives is regulable as well, satisfy to cutting the single PCB width from 5mm-100mm.

4. The blade is made of Japan imported high speed and high precision steel material, which is durable and have a long life time.

5. It is convenient to adjust the cutting speed through rotary knob

6. No limits of the cutting length.

7. Thickness range of PCB: 0.3-3.0mm

8. The machine adopts 3 blade sets to separate boards with simple operation and high efficiency to avoid bending issue.



Specification:

Model SMTAD3
Max cutting length No limit
Min cutting length 200mm
Max panel width 250mm
Custom cutting width 300mm
Min PCB width 5mm
PCB thickness 0.3-3.0mm
Feeding speed 0-500mm/s
Working tem. 10-35℃
Blade material(auto-lock function) Imported high precision steel
Storge tem. -20-50℃
Voltage 110-220V
Dimension 610x370x400mm
Packaging weight 80kgs



Multi-blade PCB Application:

Multi Blade PCB Separator Machine Unlimited Cutting Length 220VAC 0
